1 Pole 32A Schneider Miniature Circuit Breaker

Price - Rs. 1,750.00

WEDABIMA HARDWARE Electrical Products

0774953653

info@wedabimahardware.lk

Sausiri Complex , High Level Road , Nugegoda

Description

Brand - Schneider

Model - A9N1P32C

Range of Product - Distribution

Product or Component Type - Acti9

Range - Acti9

Product name - XC60

Product or Component Type - Miniature circuit-breaker

Device short Name - XC60

Poles Description - 1P

Number of Protected Poles - 1

[In] Rated Current - 32 A

Network Type - DC/AC

Trip Unit Technology - Thermal-magnetic

Curve Code - C

Utilisation Category - Category A conforming to EN/IEC 60947-2

Suitability for Isolation - Yes conforming to EN/IEC 60947-2

Complementary

Network frequency - 50/60 Hz
[Ue] rated operational voltage - 220...240 V AC 50/60 Hz 12...48 V DC
60 V DC
Magnetic tripping limit - 8 x In +/- 20 %

Breaking capacity - 10000 A Icn at 240 V AC 50/60 Hz conforming to EN/IEC 60898-1
10 kA Icu at 220...240 V AC 50/60 Hz conforming to EN/IEC 60947-2
15 kA Icu at 12...48 V DC conforming to EN/IEC 60947-2
6 kA Icu at 60 V DC conforming to EN/IEC 60947-2

[Ics] rated service breaking capacity - 15 kA conforming to EN/IEC 60947-2 - 12...48 V DC
6 kA conforming to EN/IEC 60947-2 - 60 V DC
7.5 kA conforming to EN/IEC 60947-2 - 220...240 V AC 50/60 Hz

Limitation class - 3 conforming to EN/IEC 60898-1
3 conforming to EN/IEC 60947-2

[Ui] rated insulation voltage - 500 V AC 50/60 Hz conforming to EN/IEC 60947-2

[Uimp] rated impulse withstand voltage - 6 KV conforming to EN/IEC 60947-2
Contact position indicator - Yes
Control type - Toggle

Local signalling - ON/OFF indication
mounting mode - Clip-on
mounting support - 35 mm DIN rail
Comb busbar and distribution block compatibility - Top: YES
9 mm pitches - 2
Height - 85 mm
Width - 18 mm
Depth - 77.5 mm
net weight - 0.115 kg
Colour - White

Mechanical durability - 20000 cycles
Electrical durability - 10000 cycles
Connections - terminals Biconnect (top)
Tunnel type terminals (bottom) 25 mm² flexible
Tunnel type terminals (bottom) 35 mm² rigid

Wire stripping length - 13 mm for top or bottom connection
Tightening torque - 3.5 N.m
Earth-leakage protection - Separate block
Product compatibility - C60 auxiliary
C60 accessories
Overvoltage category - IV

Environment
Standards EN/IEC 60947-2 EN/IEC 60898-1
Pollution degree - 3
Tropicalisation - 2 conforming to IEC 60068-1
Relative humidity - 95 % at 55 °C
ambient air temperature for operation - 30…70 °C
ambient air temperature for storage - 40…85 °C

Packing Units
Unit Type of Package 1 - PCE
Number of Units in Package 1 - 1
Package 1 - Height 2 cm
Package 1 - Width 7.6 cm
Package 1 - Length 8.4 cm
Package 1 - Weight 126 g
