2 Pole 63A 100MA Residual Current Circuit Breaker

Price - Rs. 17,150.00

WEDABIMA HARDWARE Electrical Products

0774953653

info@wedabimahardware.lk

Sausiri Complex , High Level Road , Nugegoda

Description

Brand - Schneider

Model - EZ9R56263

Range of Product - Easy9

Product or Component Type - Residual current circuit breaker (RCCB)

Device short Name - Easy9 RCCB

Poles - 2P

Neutral Position - Left

[In] Rated Current - 63 A

Network type - AC

Earth-leakage sensitivity - 100 mA

Earth-leakage protection time delay - Instantaneous

Earth-leakage protection class Type - AC

Rated breaking and making capacity - 500 A

Rated conditional short-circuit current - Easy9 MCB: 6000 A 40 A

Complementary
Device location in system - Outgoer
Network frequency - 50/60 Hz

[Ue] rated operational voltage - 230 V AC 50/60 Hz
Residual current tripping technology - Voltage independent
[Ui] rated insulation voltage - 440 V AC

[Uimp] rated impulse withstand voltage - 4 kV
Surge current - 250 A
Contact position indicator - Yes
Control type - Toggle
mounting mode - Clip-on
mounting support - DIN rail
Comb busbar and distribution block compatibility Top: YES
Connection pitch - 18 mm between phases

9 mm pitches - 4

Height - 82 mm

Width - 36 mm

Depth - 72 mm

Colour - Grey (RAL 7035)

Mechanical durability - 5000 cycles

Electrical durability - AC:2000 cycles 230 V AC 50/60 Hz

Connections - terminals Tunnel type terminal (top or bottom) 1…35 mm² rigid

Tunnel type terminal (top or bottom) 1…25 mm² flexible

Tightening torque - 3.5 N.m top or bottom

Environment
Standards - IEC 61008-1
Product certifications - CE
IP degree of protection - IP20
Pollution degree - 2 conforming to IEC 61008-1
Tropicalisation - 2
Relative humidity - 95 % at 55 °C
ambient air temperature for operation - 5…60 °C
ambient air temperature for storage - 40…85 °C

Packing Units
Unit Type of Package 1 - PCE
Number of Units in Package 1 - 1
Package 1 Height - 8 cm
Package 1 Width - 4 cm
Package 1 Length - 9 cm
Package 1 Weight - 212 g

Unit Type of Package 2 - BB1
Number of Units in Package 2 - 6
Package 2 Height - 9.2 cm
Package 2 Width - 9.7 cm
Package 2 Length - 25.5 cm
Package 2 Weight - 1.78 kg

Unit Type of Package 3 - S03
Number of Units in Package 3 - 54
Package 3 Height - 30 cm
Package 3 Width - 30 cm
Package 3 Length - 40 cm
Package 3 Weight - 15.264 kg
