3 Pole 32A Schneider Miniature Circuit Breaker

Price - Rs. 8,130.00

WEDABIMA HARDWARE Electrical Products

0774953653

info@wedabimahardware.lk

Sausiri Complex , High Level Road , Nugegoda

Description

Brand - Schneider

Model - A9N3P32C

Device application - Distribution

Range of Product - Acti9

Range - Acti9

Product name - XC60

Product or Component Type - Miniature circuit-breaker

Device short Name - XC60

Poles Description - 3P

Number of Protected Poles - 3

[In] Rated Current - 32 A

Network Type - AC/DC

Trip Unit Technology - Thermal-magnetic

Curve Code - C

Utilisation Category - Category A conforming to EN/IEC 60947-2

Suitability for Isolation - Yes conforming to EN/IEC 60947-2

Complementary

Network frequency - 50/60 Hz

[Ue] rated operational voltage - 240 V AC 50/60 Hz
380...415 V AC 50/60 Hz
100...125 V DC

Magnetic tripping limit - 8 x In +/- 20 %

Breaking capacity - 10000 A Icn at 240 V AC 50/60 Hz conforming to EN/IEC 60898-1
10000 A Icn at 415 V AC 50/60 Hz conforming to EN/IEC 60898-1
10 kA Icu at 380...415 V AC 50/60 Hz conforming to EN/IEC 60947-2
15 kA Icu at 100...125 V DC conforming to EN/IEC 60947-2

[Ics] rated service breaking capacity - 7.5 kA conforming to EN/IEC 60947-2 - 380...415 V AC 50/60 Hz
15 kA conforming to EN/IEC 60947-2 - 100...125 V DC

Limitation class - 3 conforming to EN/IEC 60898-1
3 conforming to EN/IEC 60947-2

[Ui] rated insulation voltage - 500 V AC 50/60 Hz conforming to EN/IEC 60947-2

[Uimp] rated impulse withstand voltage - 6 KV conforming to EN/IEC 60947-2
Contact position indicator - Yes
Control type - Toggle

Local signalling - ON/OFF indication
mounting mode - Clip-on
mounting support - 35 mm DIN rail
Comb busbar and distribution block compatibility - Top: YES

9 mm pitches - 6
Height - 85 mm
Width - 54 mm
Depth - 77.5 mm
net weight - 0.31 kg
Colour - White

Mechanical durability - 20000 cycles
Electrical durability - 10000 cycles
Connections terminals - Tunnel type terminals (bottom) 16 mm² flexible
Tunnel type terminals (bottom) 25 mm² rigid
Biconnect (top)

Wire stripping length - 13 mm for top or bottom connection
Tightening torque - 3.5 N.m
Earth-leakage protection - Separate block
Product compatibility - C60 auxiliary
C60 accessories

Overvoltage category - IV

Environment
Standards EN/IEC 60898-1
EN/IEC 60947-2

Pollution degree - 3
Tropicalisation - 2 conforming to IEC 60068-1
Relative humidity - 95 % at 55 °C
ambient air temperature for operation - 30…70 °C
ambient air temperature for storage - 40…85 °C

Packing Units
Unit Type of Package 1 - PCE
Number of Units in Package 1 - 1
Package 1 Height - 8.8 cm
Package 1 Width - 9 cm
Package 1 Length - 6.6 cm
Package 1 Weight - 340 g

Unit Type of Package 2 - BB1
Number of Units in Package 2 - 6
Package 2 Height - 8.6 cm
Package 2 Width - 9.6 cm
Package 2 Length - 24.2 cm
Package 2 Weight - 1.4 kg

Unit Type of Package 3 - CAR
Number of Units in Package 3 - 48
Package 3 Height - 27.8 cm
Package 3 Width - 30.4 cm
Package 3 Length - 35.8 cm
Package 3 Weight - 17.44 kg

wedabima.com and D Factor Group make no warranty or representation for any products, services, deals and transactions between the user and the advertisers. Users strictly at their own risk.

Related Items

4 Pole - 06A Schneider Miniature Circuit Breaker

Rs. 13,140.00

BUY NOW VISIT STORE | WEDABIMA HARDWARE Electrical Products

4 Pole - 06A Schneider Miniature Circuit Breaker price in Sri Lanka. Best deals from වැඩබිම.com for Hardware items in Sri Lanka. Brand - Schneider Model - A9N4P06C Device application - Distribution Range of, etc... Find best deals from වැඩබිම

0774953653

TV socket Kevilton - Rathnapura

Rs. 00.00 | Ask for price

VISIT STORE | Sample Advertisement

TV socket Kevilton - Rathnapura price in Sri Lanka. Best deals from වැඩබිම.com for Hardware items in Sri Lanka. Electrical Works (singal phase & three phase) CC TV cameras and distortion All electricity activities All plumbi, etc... Find best deals from වැඩබිම

0703953651

2 Pole 63A Schneider Isolater

Rs. 6,130.00

BUY NOW VISIT STORE | WEDABIMA HARDWARE Electrical Products

2 Pole 63A Schneider Isolater price in Sri Lanka. Best deals from වැඩබිම.com for Hardware items in Sri Lanka. Brand - Schneider Model - A9S2P063 Range of Product - ISW 40...125 Range - Acti9 Product or Compon, etc... Find best deals from වැඩබිම

0774953653

63A 3P - 25KA Schneider Circuit Breaker

Rs. 37,940.00

BUY NOW VISIT STORE | WEDABIMA HARDWARE Electrical Products

63A 3P - 25KA Schneider Circuit Breaker price in Sri Lanka. Best deals from වැඩබිම.com for Hardware items in Sri Lanka. Brand - Schneider Model - LV510305 Range of Product - EasyPact Product Name - EasyPact CVS , etc... Find best deals from වැඩබිම

0774953653

4 Pole 40A 30MA Residual Current Circuit Breaker

Rs. 18,150.00

BUY NOW VISIT STORE | WEDABIMA HARDWARE Electrical Products

4 Pole 40A 30MA Residual Current Circuit Breaker price in Sri Lanka. Best deals from වැඩබිම.com for Hardware items in Sri Lanka. Brand - Schneider Model - EZ9R36440 Range of Product - Easy9 Product or Component , etc... Find best deals from වැඩබිම

0774953653

2 Pole 40A Schneider Switch Disconnector
